What does a Digital Multimeter Measure?

What is digital multimeter?

The multimeter is an electronic device that is used to measure some electrical and electronic properties. In short by which device we measure multiple electrical and electronic quantities is called a multimeter. The multimeter is a measuring device that is used to measure resistance, capacitance, continuity, and other tests. It is an indispensable device that uses more in all the electrical and electronic sectors. However, there are two main types of multimeters, such as analog and digital. An Analog multimeter uses to measure voltage, current, and resistance. A Digital meter is also used to measure such things. However, let’s see what does a digital multimeter measure, how does multimeter is used, and many more.

What is the function of multimeter?

The multimeter is an electrical and electronic property measuring device. It is also used to measure AC and DC current and it is sometimes called an AVO meter. However, the function of the multimeter is very simple but it is made of an integrated circuit (IC) large scale integrated circuit (LSIC), LED light is used on the multimeter screen, and some other electronic components. It has a selector switch that is used to select voltage, current, ohm, Ac, and DC portions.


The entire portion has an indication so that you can select it easily. It has two probes (red and black) red probe indicates positive and the black color probe indicates negative terminal. Suppose you want to measure battery voltage then you have to select the voltage level and connect the positive and negative terminals of the digital multimeter connect with the battery’s positive and negative terminal. Now you can see the DC voltage in your digital meter display. So check the electrical property whatever you want based on the digital multimeter configuration.

What does a multimeter measure?

It is good to see that the digital multimeter is only the meter or tester tool that is used to measure different quantities with a meter. However digital multimeter measure voltage, current, resistance, resistor selection, diode testing, and capacitance, you can find the terminal also, find the wire by checking it through this multimeter, and you are able to do a continuity test. In a simple speech, it is an indispensable measuring instrument for every electrical and electronic purpose. It is noted that a multimeter is mainly used to measure voltage, current, resistance, and continuity.

What is a multimeter and how does it work?


The multimeter is an electronic device that is used to measure electrical and electronic properties. It is an electronic smart testing tool and multimeter used for more for any industrial or homework. It is noted that everything is given in the digital multimeter whatever you need you can select it and measure. However, let’s see how the multimeter works. Follow some steps of the digital multimeter working process.

  • First of all, open the multimeter and make it prepare to measure quantity.
  • Select the AC voltage portion to measure AC voltage. In this case, keep the two probes in line and neutral portion, now you will get the AC voltage (220 V).
  • If you want to measure DC current then select DC current portion and keep the positive and negative probe to the positive and negative portion of the device which you want to measure. If there is no issue then you will see the exact DC current.
  • You may check DC voltage by the same thing but you have to select the DC voltage portion.
  • If you want to test the continuity keep positive and negative probes to the two terminals of the device, if it makes a sound then the device is good or if it does not make a sound then it is not eligible to use.

What does a multimeter do?

We have faced a question several times of what does a digital multimeter measure. Digital or analog multimeters both are the tester that is used to test the multi-function of the device. Digital multimeter measure resistance, voltage, current, polarity check, continuity test, and another electrical and electronic quantity checking. Before making any installation the engineers use this digital device to check such electrical values. So it is an indispensable device in electrical and electronic history.

What does ohms look like on a multimeter? / How to measure resistance?

How to measure ohm? If you would like to measure ohms on a multimeter or if you would like to measure resistance then you have to select a multimeter and connect the black probe on the common port and the red probe to the voltage port and select your multimeter to ohm portion (selection ohm range is 200 R to 20 M).

First of all, you may select 200 R based on your selected resistor capacity. Now test your resistance by the positive and red probe with two portions of the resistance if your resistance shows 9.5 Ω then you become sure that it is a 10 Ω resistance. It is noted that your tested resistor resistance value can fluctuate due to tolerance. So it is the actual method to measure the ohm of your resistor.

What is the accuracy of a multimeter?


A multimeter is a static electronic measuring device that is used to measure electrical properties. It can perfectly measure voltage, current, and resistance. The multimeter accuracy depends on the type of measurement it is performing and the range of measurements it can perform. For example, the accuracy of a digital multimeter is ±1% or sometimes lesser than it. It means sometimes the voltage level can be fluctuating due to some issues. It is noted that digital and analog both are high accuracy multimeter. But if we say by the overall consideration then we see that a digital multimeter will be more accurate than an analog one.

How to understand a multimeter?

A multimeter is a device that measures the voltage and current in an electric circuit. It can also measure resistance, capacitance, and inductance as well as other parameters such as temperature. A multimeter has two metal probes that are placed into the circuit to measure its parameters. A multimeter is used for measuring voltage, current, and resistance. It can be analog or digital.

An analog multimeter has a needle that moves across the scale to show the reading. A digital multimeter has a display screen with numbers. The first thing to do is to set the range of the meter by turning the dial on the front of it so that it matches what you want to measure. For example, if you want to measure current, then turn the dial so that it reads “amps.” If you want to measure voltage, turn it so that it reads “volts.” You can measure resistance, capacitance, and some other electrical property in this way.

Can you measure amps with a multimeter?

Yes, you are able to checking amps with a multimeter by a simple process. But there is a question how do you test current with a multimeter? In this case, you have to connect it in series if you connect it in parallel then you have a chance to destroy your digital multimeter due to its low resistance. So never connect it in parallel with the meter. For this reason, connect it in series to measure ac amps with multimeter


However, let’s discuss about connection first of all connect your black probe in the common port and connect the red probe with mili ampere (mA). Now connect the positive and negative portions of the meter with both terminals of your device then you will see that meter is showing current. It is noted that you may measure the current in ampere (A) or mili ampere (mA).

Can you test resistor with digital multimeter?

The straightforward answer is yes, you can test the resistor with a digital multimeter. However, there is a common question, how to test resistance with digital multimeter? It is very simple to find resistance. First of all, you need a resistance checking digital multimeter to connect the black probe to the common port and volt-ampere (VA) port change your digital multimeter ohm setting and keep it in a minimum resistance point of the multimeter. Now you can test your resistor. In this case, you need to connect two probes of the meter with the two-point of the resistor.


It is noted that when you find resistance then you don’t need to think about the positive and negative probe. However, if your resistor does not show any value then you need to increase resistance (change the meter switch to 2KΩ then you will get the resistance). Suppose you have selected the multimeter nob to 2 KΩ and you are not getting a value. In this case, change your nob to 200 KΩ then you will get your required resistance. It is noted that if your resistor does not show any value (shown 0.0) then you have to think that it is not a useable resistor. So test your resistor by following this crucial way.

Diode testing using multimeter

If you want a test diode then you need a digital multimeter. Now keep your meter rotating nob in the diode mode in multimeter. Press the left-side yellow button of your meter to show the diode symbol in the display. After completing the diode setting on multimeter, you can connect the positive (red) and negative probe (black) to the diode positive and negative terminals (anode and cathode). You should remember that never connect the negative probe to the diode positive probe and the positive pro to the diode negative terminal.


Then you will not get any results. It is because the diode allows to flow of electricity in one direction only (anode to cathode). So keep it connect correctly with positive and negative terminals and get the right value. It is noted that the diode gives a value from 0.500 to 0.600 if the diode becomes inefficient to use then it will not show any result. So, you can follow this way to diode testing using multimeter.

Can you measure capacitance with a multimeter?

Can a multimeter measure capacitance? Yes, you can measure capacitance with a multimeter. In this case, you may follow two ways to measure capacitance with a multimeter. One is by using the time constant measurement and the other is by using the frequency measurement. It is noted that the entire multimeter is not able to measure capacitance, you need a highly configure multimeter.

Can you test a capacitor with a digital multimeter?

A capacitor is an electronic component that stores energy in the form of a static electric field. It consists of two metal plates usually made from aluminum or tantalum, separated by a dielectric material. In this section, you will learn how to test a capacitor with a digital multimeter. To test a capacitor with a digital multimeter, first, connect the positive lead to the positive terminal and the negative lead to the negative terminal. The meter should read 0 volts if there is no charge on the capacitor. Second, measure the voltage between both terminals and then check if it’s within the tolerance range for your device (if not, replace it).

Final thought of what does a digital multimeter measure

The multimeter is a measuring instrument. A digital multi meter is usedfor measuring electrical and electronic properties. We have shown above what does a digital multimeter measure and how it is important for any installation and measuring any electrical property. There are two main types of multimeters digital and analog but we have told about digital multimeters. It is the easiest and mostly needed for measuring applications. Indeed there are different types of digital multimeter brands that design for measuring purposes. So, get in touch with openread to more about electrical and electronics and other innovative things.
